| Physics | |
 |
 |
 |
 |
 |
 |
 |
| RTF Technologies' Physics describes devices that deal with fundamental particles, forces, electric and magnetic fields, as well as nuclear reactions. | |
 |
Deuterium fusion reactor (fusor) for neutron production. Will utilize Inertial Electrostatic Confinement and include ion sources. |
 |
Mass production anode layer ion source |
 |
A Faxitron DX-50 cabinet x-ray system is converted into a small CT scanner to scan electronic components. |
 |
Teardown of a Faxitron DX-50 cabinet x-ray system, the unit was damaged in shipping resulting an a broken x-ray tube and bad power supply. The unit is dismantled and analyzed. |
 |
Radiation Shielded Camera 4 / Gear 360 Videos
|
 |
Radiation Shielded Camera Version 4 A GoPro Hero 3+ silver, GoPro Session, Gear360, and Casio Exilim EX-ZR200, were shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. Radcam version 4 is an improved version of earlier Radcam versions including two GoPro cameras, a 1000fps high speed camera, a 360 degree panoramic camera, and a high range ion chamber connected to a high speed data logger. Data and videos taken are used to corilate the detected x-ray speckle on the video with actual x-ray radiation levels in the irradiator. Camera construction |
 |
A Gear360 was shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. Camera construction |
 |
Radiation Shielded Camera Version 3 A GoPro Hero 3+ silver camera and thermal-eye 2500AS thermal imager were shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. Radcam version 3 is an improved version of radcam2 including a thermal imager, more secure camera mounts, and external power feedthroughs for the Gopro alowing charging inside the lead box. The plastics were used to produce lichtenberg figures. Camera construction |
 |
A GoPro Hero 3+ silver camera and thermal-eye 2500AS thermal imager were shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. Radcam version 3 is an improved version of radcam2 including a thermal imager, more secure camera mounts, and external power feedthroughs for the Gopro alowing charging inside the lead box. The plastics were used to produce lichtenberg figures. Video/pictures of the irradiation run from the camera. |
 |
Radiation Shielded Camera Version 2 A GoPro Hero 3+ silver camera was shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. The plastics were used to produce lichtenberg figures. Camera construction |
 |
A GoPro Hero 3+ silver camera was shielded with lead and sent through an industrial irradiator while viewing plastic and mineral samples. The plastics were used to produce lichtenberg figures. Video/pictures of the irradiation run from the camera. |
 |
A sony cybershot DSC-P72 camera was shielded with lead and HDPE and sent through an industrial irradiator while viewing plastic and mineral samples. The plastics were used to produce lichtenberg figures. |
 |
A terrella (permanent magnet simulating the interaction of plasma with earth's magnetosphere) was inserted into the edge plasma of Madison symmetric torus and imaged with an 80k frames/sec camera. |
 |
100 KeV Pulsed Electrostatic Particle Accelerator This is a small electrostatic particle accelerator that utilizes a pulsed electric field to accelerate electrons to 100 KeV. The utilization of an oil diffusion pump coupled to a rotary vane pump provides a vacuum level of 1.5E-5 torr. |
 |
Spherical deuterium fusion reactor for neutron production / subsystem evaluation. Core machined for practice in fabricating stainless steel vacuum systems. |
 |
Nancy Wood BF3 Neutron Detector Ludlum model 12 and Nancy Wood BF3 tube in HDPE moderator |
 |
SAIC Exploranium GR-135ND-H Plus porttable radioisotope identifier and neutron detector. |
 |
Nuclear Chicago DN-3 Neutron Probe Nuclear Chicago DN-3 neutron probe |
 |
Eberline R0-7 Ion Chamber, high range survey meter with interchangable probe heads. Modified for use between 20kR/h-20MR/h for irradiator testing |
 |
Eberline PNC-4 Neutron Detector Eberline PNC-4 neutron detector |
 |
Eberline PNC-1 Neutron Detector Eberline PNC-1 neutron detector |
 |
Small Deuterium fusion reactor prototype for concept testing and design evaluation. Utilizes Inertial Electrostatic Confinement. |
 |
Heavy Water Electrolysis Assembly Fuel converter for producing deuterium by electrolyzing heavy water. |
 |
This Van De Graaf generator was built for testing the particle accelerator and for other electrostatic experiments. |
 |
Modification of a CCD camera for use as a vertex detector for high energy particles and gamma rays. |
